Sniper EFI Throttle Body
Type: Throttle Body
Sniper EFI's new 90mm billet aluminum throttle bodies are designed as a direct fit for the Fabricated Race intake manifolds. Our throttle bodies are feature packed, available in both bright silver or black anodized finishes. The enlarged bore sizes allow for increased airflow to support your higher horsepower needs, a progressive throttle pulley enhances low speed drivability and a double return spring provides solid and secure throttle control feel.
Features:
- Cable operated throttle body available in 90mm opening
- Enlarged bore allows increased airflow to support higher horsepower requirements
- Built specifically for Sniper EFI Race intake manifolds
- High quality billet aluminum construction
- Choice of bright silver or black anodized finish
- Laser engraved Sniper EFI logo
- Progressive throttle pulley and double return spring
- Adjustable throttle stop
- 4-bolt style mounting pattern, bolts included
Specs:
- Billet Color: Silver
- Brand: Holley Sniper EFI
- Category: Air and Fuel Delivery
- Emission Code: 8
- Finish: Silver
- Fuel Injectors Included: No
- Gasket Or Seal Included: No
- IAC hardware specs: (2) 8-32 UNC
- Idle Air Control Motor Included: No
- Material: Billet Aluminum
- Mounting Hardware Included: Yes
- Part Type: Fuel Injection Throttle Body
- Product Type: Throttle Body
- Sub Category: Fuel Injection System and Related Components
- Throttle Body Spacer Included: No
- Throttle Bore: 90 MM
- Throttle Diameter (mm): 90 MM
- Throttle Position Sensor Included: No
- TPS hardware specs: (2) M4 x 0.7
- Transmission: N/A
- Warranty: Limited 90 Day
Tech Resources:
Will need to use 543-34 for IAC sensor and 870001 for TPS sensor listed under Parts & Kits tab. IAC motor attaching hardware: requires (2) 8-32 UNC screws; TPS sensor attaching hardware: requires (2) M4 x 0.7 screws.
